Z-Shaped Conveyors

Z-shaped conveyors are engineered for controlled vertical transport of products to a defined elevation within food-processing and industrial production lines. The systems are designed in accordance with food-industry requirements, using certified materials and components suitable for direct product contact.

Application Range

Z-shaped conveyors are suitable for conveying a wide variety of products, including snacks, confectionery, nuts, cereals, vegetables, fruits, tablets, and animal feed. They are commonly used for feeding hoppers, dosing systems, and multihead weighers, ensuring stable and continuous product supply.

Design and Configuration

The conveyor is equipped with a modular belt featuring cleats or flights to secure the product during elevation. The standard configuration consists of three sections:

• Lower horizontal infeed section

• Inclined conveying section

• Upper horizontal discharge and drive section

Inclination angles and section lengths are adapted to product characteristics, throughput requirements, and installation constraints to ensure gentle handling and reliable transport.

Hygienic and Food-Grade Design

Z-shaped conveyors are designed with hygienic principles in mind, featuring easy-to-clean surfaces, food-grade belt materials, and construction suitable for washdown or dry-cleaning environments. This supports compliance with food safety standards and minimizes contamination risks.

Operation and Maintenance

The conveyor design allows for straightforward operation and maintenance. An integrated belt tensioning system enables quick compensation for belt elongation, ensuring stable tracking and long service life. Modular construction allows reconfiguration or customization to meet specific process requirements.

Key Advantages

• Reliable vertical conveying with controlled product handling

• Suitable for a wide range of food and non-food products

• Hygienic, food-grade design with certified components

• Modular construction for flexible configuration

• Low maintenance and long operational lifespan

Z-shaped conveyors provide a dependable and efficient solution for vertical product transport, supporting consistent process flow and increased production efficiency.
